Page 1

Precautions

0n satety

- As the laser beam used in the CD player
Section is harmful to the eyes, do not
attempt to disassemble the casing. Refer
servicing to qualified personnel only.
Should any solid object or liquid fall into
the player, unplug the player, and have it
checked by qualified personnel before
operating it any further.

Discs with nonstandard shapes (e.g.,
heart. square, star) cannot be played on
this player. Attempting to do so may
damage the player. Do not use such discs.

Cleaning the cabinet

- Clean the cabinet, panel and controls with
a soft cloth slightly moistened with a mild
detergent solution. Do not use any type of
abrasive pad, scouring powder, or solvent.
such as alcohol or benzine.

lln [IDWEI sources
- For AC operation, use the supplied AC
power adaptor; do not use any other type.

7c

Polarity oi the plug

The player is not disconnected from the
AC power source (mains) as long as it is
connected to the wail outlet, even if the
player itself has been turned off.

Unplug the player from the wall outlet
when it is not be used for an extended
period of time.

When the batteries are not to be used.
remove them to avoid damage that can be
caused by battery leakage or corrosion.
The nameplate indicating operating
voltage, etc. is located at the rear.

0n placement

- Do not leave the player in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or mechanical
shock.

Do not place the player on an inclined or
unstable place.

Do not place anything within 10 min of
the side of the cabinet. The ventilation
holes must be unobstructed for the player
to operate properly and prolong the life of
its components.

If the player is left in a car parked in the
sun, be sure to choose a location in the car
where the player will not be subjected to
the direct rays of the sun.

Since a strong magnet is used for the
speakers, keep personal credit cards using
magnetic coding or Springrwound watches
away from the player to prevent possible
damage from the magnet.

lln operation

- If the player is brought directly from a
cold to a warm location, or is placed in a
very damp room, moisture may condense
on the lenses inside the CD player section.
Should this occur, the player will not
operate properly. in this case, remove the
CD and wait about an hour for the
moisture to evaporate.

itotes on cos

- Before playing, clean the CD with a
cleaning cloth. Wipe the CD from the
center out.

- Do not use solvents Such as benzine.
thinner, commercially available cleaners
or antistatic spray intended for vinyl LPs.

- Do not expose the CD to direct sunlight or
heat sources such as hot air ducts, nor
leave it in a car parked in direct sunlight as
there can be a considerable riSe in
temperature inside the car.

- Do not stick paper or sticker on the CD,
nor scratch the Surface of the CD.

- After playing, store the CD in its case.

if there is a scratch, din or fingerprints on the

CD, it may cause tracking error.

itltont CD-RSIcD-IIWS

This player can play CDrRs/CDrRWs

recorded in the CDrDA format*, but

playback capability may vary depending on

the quality of the disc and the condition of

the recording device.

* CDrDA is the abbreviation for Compact
Disc Digital Audio. It is a recording
standard used for Audio CDs.

Music discs encoded with copyright
protection technologies

This product is designed to play back discs
that conform to the Compact Disc (CD)
standard. Recently, various music discs
encoded with copyright protection
technologies are marketed by some record
companies. Please be aware that among
those discs, there are some that do note
conform to the CD standard and may not by
playable by this product.

if you have any questions or problems
conceming your player, please consult your
nearest Sony dealer.

Troubleshooting

The power does not come on.

- Connect the AC power adaptor to a wall outlet
securely.

There is no audio.

- Make sure the function you want to use
appears in the display window.

- Adjust the volume.

- Unplug the headphones when listeiung
through speakers.

Noise is heard.

- Someone is using a portable telephone or
other equipment that emits radio waves near
the player. --Move the portable telephone.
etc., away from the player.

on Player

The CD does not play or no disc"
lights in the display even when a CD
is in place.

Place the CD won the label surface you.
Make sure that the CD compartment is closed,
Clean the CD.

Take out the CD and leave the CD
compartment open for about an hour to dry
moisture condensation.

Make sure Cd" appears in the display.

The CD-R/CD-RW was not finalized. Finalize
the CD-R/CD-Rw with the recording device.
There is a problem with the quality of the CD-
R/CD-RW, recording device, or application
software.

The sound drops out.

Noise is heard.

Reduce the volume.

Clean the CD, or replace it if the CD is badly
damaged.

Place die player in a location free from
vibration.

Clean the lens with a commercially available
blower.

The sound may drop out or noise may be
heard when using poor quality CD-Rs/CD-
RWs or if there is a problem With the
recording device or application software.

Lens

Reception is poor.
- Reonent the antenna to improve FM
reception.

~ Reonent the player itself to improve AM
reception.

The audio is weak or has poor quality.

- Move the player away from the TV.

- If you are using the remote while listening to
AM radio, noise may be heard This is
unavoidable.

The picture oi yourTV becomes

unstable.

- If you are listciung to an FM program near the
TV with an indoor antenna, move the player
away from the TV.

ROIIWIB

The remote does not function.

Replace the battery in the remote with new
one if it is weak.

Make sure that you are pointing the remote at
the remote sensor on the player.

Remove any obstacles in the path of the
remote and the player,

Make sure the remote sensor is not exposed to
strong light such as direct sunlight or
fluorescent lamp light.

Move closer to the player when using the
remote.

After trying the above remedies, if you still have
problems. unplug the AC power adaptor. After
all the indications in the display disappear, plug
the AC power adaptor. If the problem persists,
please consult your nearest Sony dealer.

Specifications

AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION

With 6-ohrn loads, both channels driven
from 1000 r 10 000 Hz; rated 3.5 W per
channelrrninimum RMS power, with no
more than 10 % total harmonic distortion
in AC operation.

other specifications

CD player section
System
Compact disc digital audio system
Laser diode propenicr
Material: GnAtAs
Wave length: 730 nm
Emission duration: Continuous
Loser output: Less than 44.6 (M
(This output is the value measured at a distance
of about zoo mm from the objective lens surface
on the optical pick-up block with 7 mm
apcnure.)
Spindle speed
200 mm (rpm) to 500 r/rriin (rpm)
(CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +l/-2 dB
Wow and flutter
Below measurable limit

Radio section
Frequency range

FM 87.5 - 108 MHz

AM:531- l 611 kHz (Taiwan model)

530 - l 710 kHz (Other models)

Antennas

FM Telescopic antenna

AM: Built-in ferrite bar antenna

General
Speaker
Fullrango s cm (3 V4 in.) din.. on, cone type
(2)
input
LINE LN jack (stereo ntinijaclr):
Minimum input level 330 mv
Outputs
Headphones Jack (stereo minijnck),
For 16 - 68 n impedance headphones
OPTICAL DIGITAL our (CD) (optical output
connector):
Wavelength 63D - 690 nm
Power output
4 w +4 w (at 6 (2,10% harmomc
distortion)
Powcr requirements
For Personal Audio System:
DC 1N lDV jack accepts: Supplied AC power
adaptor for use with: 120v AC, 60 Hz
For remote control,
3 v DC. 2 size AAA (R03) batteries
Dimensions
Approx. 530 x 195 x 127 mm (w/h/d)
(20 7/i x 7 2/. X 5 inches) (incl, projecting parts)
Mass
Approx. 2.5 kg (5 lb. 8 oz)
Supplied accessory
Ac power adaptor (1)
Remote control (l)

Design and specifications are subject to change
without norioe,

Optional accessories
Sony MDR headphonc series

SONE

Personal
Audio
System

Operating Instructions

28-010

@2003 Sony Corporation
Printed in China

3-251-193-91 (1)

To prevent tire or shtick halard. do
not expose the player to rain or
moisture.

Kablonnt r Hats who;

This symbol is intended to alert the
user to the presence of uninsulated
dangerous voltage" within the
products enclosure that may be of
sufficient magmtude to constitute a
risk of electric shock to persons.

This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instmcuons in the
literature accompanying the
appliance

%

CAUTIOII
Tite use of optical instruments With diis product
WIII increase eye hazard.

WAIIIIIIIG

Do not install the apphance in a confined space.
such as a bookcase or built-in cabinet.

To prevent fire or shock hazard. do not place
objects filled with liquids, such as vases, on the
appliance.

For customers in Canada
To prevent electric shock. match wide blade of
plug to wide slot, fully insert.

information

For customers In the USA

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Pan 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against han-niul interference in a

residential installation This equipment

generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications

However, there is no guarantee that interference

will not occur in a particular installation. if this

equipment does cause harmful interference to
radio or television reception, which can be
detemuned by tuming the equipment off and on.
the user is encouraged to try to correct the
interference by one or more of the following
measures:

7 Reonent or relocate the receiving antenna.

7 Increase the separation between the
equipment and receiver,

7 Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected

7 Consult the dealer or an expenenced radio/
TV technician for help.

This class B digital device complies with part 15

of the FCC rules. Operation is subject to the

following two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference received.
including interference that may cause undesired
operation.

You are cautioned that any changes or

modifications not expressly approved in this

manual could void your authority to operate this
equipment.

Replace the AC power adaptor with model AC-
CD10 only, if replacement is nec sary.

Owners Record

The model number and serial number are located
at the rear.

Record the serial number in the space provided
below. Refer to them whenever you call upon
your Sony dealer regarding this product.

Model No. ZS-DIU

Send] No.

For customers In the USA

Please register this product on line at http://
wwwsonyeoni/productregistration.

Proper registration will enable us to send you
periodic mailings about new product.
services and other important announcements.
Registering your product Will also allow its to
contact you in the unlikely event that the
product needs adjustment or modification.
Thank you.

hilp://www.sony.nel/

Power Sources

Connect the AC power adapter I.

Preparing the remote E]

Insert two size AAA (R03) batteries (not supplied).

iteplacing batteries

2 to a wall outlet

With normal use, the batteries should last for about six months. When the remote no longer
operates the player. replace two batteries with new ones.

Page 2

Location of controls

ltemote Control
RADIO
BAND
AUTO PRESET MEMORY
K4, DISPLAY powen
PRESET -, + ENTER

OPERATION Indicator

LINE 0 LINE IN

MEGA BASS
VOLUME -, +

Flemote sensor

OPEN OPTICAL DIGITAL OUT (CD)

*The button has a tactile dot.

Loading a Cl)

WIth the labeled side facing you

FUNCTION

>Il -

BAND

PFIESET +, -
K4 ,DH

VOL +, -

Display

Total track number -':-3| 5 5:3 7' - Total playing time

Programmed track

- Playing order

To turn onlolt the power
Press POWER.

To adlust the volume
Press VOLUME +, , (VOL +, , on the remote).

To listen through headphones
Connect the headphones to the 1. (headphones) jack.

to turn oil the blue light of the Cl] compartment lid
When the player is turned on, the blue light of the CD compartment lid lights. To turn the light
off, press and hold MODE for about 4 seconds.

To turn the light on again, press and hold MODE for about 4 seconds.

Adiusting the audio emphasis

You can adjust the audio emphasis of the sound you are listening to.
To reinforce the bass sound

Press MEGA BASS.

MEGA BASS" appears in the display.

To return to normal sound, press the button again.

Play ng a CD

1 Press POWER to turn on the player.
2 Press OPEN to load a CD in the CD compartment.
3 Close the CD compartment by hand.

4 Press D".
The player plays all the tracks once.

To Press
stop playback -
pause playback >||
Press the button again to resume play after pause.
go to the next track m
go back to the previous track K4
remove the CD OPEN
locate a point while listening >>I (forward) or H4 (backward) while playing until you
to the sound find the point
locate a point while observing >>l (forward) or t<< (backward) in pause until you mm
the display the point
Using the display

To check the total track numhcr and playing time
Press MEMORY/DISPLAY/ENTER in stop mode (see fig.

To check the remaining time
Press MEMORY/DISPLAY/ENTER repeatedly while playing a CD. The display changes as
follows:

the current track number and playing time

I

the current track number and the remaining time on the current track*

I

the number of tracks left and remaining time on the CD

* Fora crack whose number is more than 20. the remaining time appears as -: in the display.

Selecting the play mode

Press MODE until REP l" "REP ALL" SHUF' SHUF REP" PGM PGM REP" appears in
the display. Then proceed as follows:

Listening to the radio

1 Press POWER to turn on the player.

2 Press RADIO-BAND-AUTO PRESET until the band you want appears in the
display.
Each time you press the button, the indication changes as follows:
FM -. a

3 Hold down TUNE + or - until the frequency digits begin to change in the
display.
The player automatically scans the radio frequencies and stops when it finds a
clear station.
If you can't tune in a station, press the button repeatedly to change the frequency
step by step.

Tip

If the FM broadcast is noisy. press MODE until Mono" appears in the display and the radio will play in
monaural.

Presetting radio stations

You can store radio stations into the players memory. You can preset up to 30 radio stations, 20
forPM and 10 for AM in any order,.

1 Press POWER to turn on the player.
2 Press RADIO-BAND-AUTO PRESET to select the band.
3 Hold down MEMORY/DISPLAY/ENTER for 2 seconds until AUTO flashes
in the display.
4 Press MEMORY/DISPLAY/ENTER.
The stations are stored in memory from the lower frequencies to the higher ones.
It a station cannot he preset automatically
You need to preset a station with a weak signal manually.
1 Press or POWER to turn on the player.
2 Press RADIO-BAND-AUTO PRESET to select the band.
3 Tune in a station you want.
4 Hold down MEMORY/DISPLAY/ENTER for 2 seconds until the preset number flashes in
the display.
5 Press PRESET + or 7 until the preset number you want for the station flashes in the display.
6 Press MEMORY/DISPLAY/ENTER.
The new station replaces the old one.

To se|epr Then do this Tlp

repeat a single (ck REP 1.. Press K4 0, >>l ,0 select the Rack that you The preset radio stations remain in memory even if you unplug the AC power adaptor.
want to repeat, then press >ll.

W 1 mks REP L Playing preset radio stations

shuffle play Sl-l'U'F"

repeat tracks st-rm: REP" Press >ll.

in random order

Press K4 or >>I then press MEMORY/
DISPLAY/ENTER for the tracks you want to
programme in the order you want up to 20 tracks
(see fig. E1). Then press >lt.

Press l<< or m then press MEMORY/
DISPLAY/ENTER for the tracks you want to
programme in the order you want up to 20 tracks.
Then press HI.

programme play PGM

repeat programmed nacks PGM REP"

To cancel selected play mode
Press MODE until the selected mode disappears from the display.

To check the programmed track and playing order in the display
To check the order of tracks before play, press MEMORY/DISPLAY/ENTER.
Every time you press the button, the track number appears in the programmed order.

To change the current programme
Press I once if the CD is stopped and twice if the CD is playing. The current programme will be
erased. Then create a new programme fonowing the prograrrmiing procedure.

Tip
You can play the same programme again, since the programme is saved until you open the CD
compartment.

1 Press POWER to turn on the player.
2 Press RADIO-BAND-AUTO PRESET to select the band.
3 Press PRESET + or - to tune in the stored station.

Connecting optional components

You can record a CD on a MiniDisc and enjoy the sound from other components, such as
portable MD, CD player and TV, VCR through the speakers of this player.

Be sure to turn off the power of each component before making connections. For details, refer to
the instructions of the component to be connected.

Recording a Cl] on a MinilJisc recorder and CAT recorder

1 Open the jack cover of the OPTICAL DIGITAL OUT (CD) jack of this player
and connect the jack with the digital input jack of MiniDisc and DAT using the
digital connecting cable * (not supplied).

* Select a connecting cable depending on the type of the digital input Jack of the recorder to be
connected. For details, refer to the instmction manual of the component to be connected. The
OPTICAL DIGITAL OUT (CD) pick of this unit is square-shaped jack

Model number of
the connecting cable

The type of the lack
of the component
to be connected

Optical miniplug POCeSAB
(MiniDisc recorder, etc.)

Lrtype 7rpln connector POCrDAIZP
(DAT recorder, etc.)

Squarershaped optical POCrlIJA

connector (MiniDisc
recorder. DAT recorder, etc.)

2 Turn on the power of this player and the connected component.
3 Make the connected component ready for recording.
4 Press b" to start playing a CD on this player.

Listening to the sound from the connected components

1 Connect the LINE IN jack of this player with the line output jack or headphones
jack of other component using the audio connecting cable* (not supplied).
* For Minidisc recorder: a cable with a stereo-mini plug on both ends.
* For TV, VCR: a cable with a stereo-mini plug on one end and tow phono plugs on the other end.

2 Press LINE to display LInE.
3 Play the optional component connected to the LINE IN jack of the player.

Note
Connect the cords fimtly to avoid any malfunction.

Fal ng asleep to mus'c

1 Play the music source you want.
2 Press SLEEP.
3 Press SLEEP to select the minutes until the player goes off automatically.

Each time you press the button, the indication changes as follows: 60" -.
n90,,_.n120o_>nOFF, _> 10,, _. n20" _> n30n_

To cancel the sleep lunction

Press POWER to turn off the power.

Tip
The blue light of the CD compartment lid goes off while the sleeping timer is on.
