st-gsa
SERVICE MANUAL
E Model
The XRS-888 consists of the main unit (XE-3750) and the speaker unit (XS-602E)
Consequently, this service manual mentions onIy ACCESSORIES & PACKING MATERIALS.
Please refer to the previously issued XR-3750/C350 (9925646410) and XS-602F (9-925-584-IJII)
service manuals for other matters.
Rel, No. Part No. Description Remark Ref, No, Part No. Description Remark
ACCESSORIES & PACKING MATERIALS PARTS FOR INSTALLATION AND CONNECTIONS
41*>Il=************************>I0k>k *********************$*****$****x*$***
3-859-565-11 MANUAL, INSTRUCTION 501 3-916-161-31 FRAME ASSY
(ENGLISH, SPANISH, CHINESE) (XR-3750) 502 X-3370-077-1 SCREW ASSY(AE. KEY), FITTING
3-859-566-31 MANUAL, INSTRUCTION 503 X-3371-913-I SCREW ASSY (J)
(ENGLISH, SPANISH, CHINESE) (XR-3750) 504 1-775-207-21 CORD (WITH CONNECTOR) (POWER)
3-859-566-41 MANUAL, INSTRUCTION (ARABIC) (XR-3750) 505 Printed on the carton flap
3-859-566-51 MANUAL, INSTRUCTION (ARABIC) (XR-3750)
3-859-567-11 MANUAL, INSTRUCTION, INSTALL 506 1-690-882v31 CORD, SPEAKER (WHITE) (L-CH)
(ENGLISH, SPANISH, CHINESE) (XE-3750) 506 1-690-882-41 CORD, SPEAKER (GRAY) (R-CH)
507 X-3369v719-1 SCREW ASSY
3-859-567-31 MANUAL, INSTRUCTION, INSTALL
(ENGLISH, SPANISH, CHINESE) (XR-3750)
3-859-567-41 MANUAL, INSTRUCTION, INSTALL (ARABIC)
(XR-3750)
3-859-567-51 MANUAL, INSTRUCTION. INSTALL (ARABIC)
(XR-3750)
3-859-917-11 MANUAL, FITTING INSTRUCTION (ENGLISH,
FRENCH, GERMAN, SPANISH, DUTCH,
SWEDISH, ITALIAN, PORTUGUESE,
CHINESE, ARABIC)
3-859-917-21 MANUAL, FITTING INSTRUCTION (ENGLISH.
FRENCH, GERMAN, SPANISH, DUTCH,
SWEDISH, ITALIAN, PORTUGUESE,
CHINESE. ARABIC)
X-3373412-I CASE (PANEL) ASSY
S O N Y;
. 7 _
Sony Corporat-on ed $155323
9-925-622-1 1 Personal & Mobile Communication Company Publlshed by Quality Assurance Dept.
