Sony xr c 6100 w service manual

This is the 34 pages manual for sony xr c 6100 w service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 34
sony xr c 6100 w service manual

Extracted text from sony xr c 6100 w service manual (Ocr-read)


Page 1

Ð 2 Ð TABLE OF CONTENTS 1. GENERAL Location of Controls ....................................................... 3 Installation ....................................................................... 4 Connection ...................................................................... 5 2. DISASSEMBLY ......................................................... 8 3. ASSEMBLY OF MECHANISM DECK ........... 10 4. MECHANICAL ADJUSTMENTS ....................... 13 5. ELECTRICAL ADJUSTMENTS Test Mode ........................................................................ 13 Tape Deck Section .......................................................... 13 Tuner Section .................................................................. 14 6. DIAGRAMS 6-1. Printed Wiring Board Ð MAIN Section Ð ...................... 17 6-2. Schematic Diagram Ð MAIN Section Ð .......................... 19 6-3. Printed Wiring Board Ð PANEL Section Ð .................... 23 6-4. Schematic Diagram Ð PANEL Section Ð ....................... 25 6-5. IC Pin Function Description ........................................... 30 7. EXPLODED VIEWS ................................................ 33 8. ELECTRICAL PARTS LIST ............................... 36 Flexible Circuit Board Repairing ¥ Keep the temperature of the soldering iron around 270 ûC dur- ing repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ¥ Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be dam- aged by heat.

Page 2

Ð 3 Ð SECTION 1 GENERAL This section is extracted from instruction manual.
