Sony xr c 2300 x service manual

This is the 32 pages manual for sony xr c 2300 x service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 32
sony xr c 2300 x service manual

Extracted text from sony xr c 2300 x service manual (Ocr-read)


Page 1

2 TABLE OF CONTENTS 1. GENERAL Location of Controls ....................................................... 3 Setting the Clock ............................................................. 3 Installation ....................................................................... 4 Connections ..................................................................... 5 2. DISASSEMBLY ......................................................... 7 3. MECHANICAL ADJUSTMENTS ....................... 10 4. ELECTRICAL ADJUSTMENTS Test Mode ........................................................................ 10 Tape Deck Section .......................................................... 10 Tuner Section .................................................................. 12 5. DIAGRAMS 5-1. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 14 5-2. Printed Wiring Board – MAIN Board – ......................... 15 5-3. Schematic Diagram – MAIN Board (1/2) – ................... 16 5-4. Schematic Diagram – MAIN Board (2/2) – ................... 17 5-5. Printed Wiring Board – KEY Board – ........................... 18 5-6. Schematic Diagram – KEY Board – .............................. 19 5-7. IC Pin Function Description ........................................... 21 6. EXPLODED VIEWS ................................................ 23 7. ELECTRICAL PARTS LIST ............................... 26Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. - Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). - Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement - Never reuse a disconnected chip component. - Notice that the minus side of a tantalum capacitor may be dam- aged by heat.

Page 2
