Sony xr 1300 service manual

This is the 29 pages manual for sony xr 1300 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 29
sony xr 1300 service manual

Extracted text from sony xr 1300 service manual (Ocr-read)


Page 2

TABLE OF CONTENTS

Section Title Page

. GENERAL

Location and Function of Controls~
Listening to the Tape Playback
Setting the Clock ~
Tuning in a Station
Using the Memory Preset Tuning ..
Installation
Connections


éxa'anuutzJaw

EXPLANATION OF IO TERMINALS ~~~~~~~~~~~~~~~~~~~~~~~ 8

ADJUSTMENTS
3-1. Mechanical Adjustments .
3-2. Electrical Adjustments

. DIAGRAMS

4.1 Printed Wiring Boards ...................................... 15
4.2. Schematic Diagram .......................................... 19

EXPLODED VIEWS

5-1 Chassis Assemblyd
5-2i Chassis Assembly-2""
S-3i MD Section-1
5-4. MD Section-2
5.5~ MD Section-3 .................................................. 28


ELECTRICAL PARTS LIST ..........................

Ftexible Circuit Board Repairing

Keep the temperature of the soldering iron around
270°C during repairing.

Do not touch the soldering iron on the same conduc-
tor of the circuit board (within 3 times)

Be careful not to apply force on the conductor when
soldering or unsoldering.

Notes on chip component replacement

Never reuse a disconnected chip component.
Notice that the minus side of a tantalum capacitor
may be damaged by heat.
