3 XR-1100 SECTION 1 GENERAL This section is extracted from instruction manual. The clock activates. 4Press the DSPL button momentarily. Note The clock cannot be set unless the power is turned on. Set the clock after you turn on the radio, or during tape playback. Setting the clock The clock has a 12-hour digital indication. For example, setting it to 10:08 1Display the time. (Press the DSPL button during unit operation.) 2Press the DSPL button for more than two seconds. Set the hour digits. 3Press the SOUND button momentarily. Set the minute digits. to go forward to go back to go forward to go back The hour digit blinks. The minute digits blink. 5 GB Location of controls Refer to the pages for further details. 1SOUND (control mode select) button 6, 9, 10 2TUNER/A MEM (radio on - band select/ automatic memory) button 8, 9 3 (volume/bass/treble/balance/ fader control) buttons 6, 9 4Z (eject) button 7 5Display window 6m/M (fast winding)/DIR (tape transport direction change) buttons 7 D-BASS DSPL 23456 1 LOCAL SOUND OFF ATA A MEMTUNER SEEK MANU XR-1100 DIR 7D-BASS button 9 8OFF button 9During radio reception: Preset number buttons 9 During tape playback: 1ATA (Automatic Tuner Activation) button 7 q;Frequency select switch (located on the bottom of the unit) (E and UK models only) See Frequency select switch in the Installation/Connections manual. qaSEEK/MANU button 8 qsLOCAL (local seek) button 8 qdDSPL (display mode change/time set) button 6 Ver 1.1 2001.06
