Page 2
WM-FX30
Note :
«Follow the removal procedue in the numerical order given.
Cabinet (rear) assy
Mechanism and Main board
0 Remove mechanism deck main board
to the direction of arrow.
front cabinet assy and
cassette lid assy
head flexible boa rd
SECTION 1
DISASSEMBLY
0 Insert the precision screw driver
(1.4mm flabblade) in to the slit
at claw 0 and release the claw.
0 Remove the cabinet
cabinet (rear) assy (rear) assy. (Release
all claw 0 to 0 in
alphabetical order)
0
mechanism deck
and main board
* note for installation :
Make sure to put the head flexible
board to ditch before install the
mechanism deck and main board.
