Sony wm fx 163 service manual

Page 1

Ð 2 Ð Sony Corporation Personal A&V Products Company 9-923-302-11 98A0570-1 Printed in Japan © 1998. 1 Published by Quarity Engineering Dept. (Shibaura) 11 X-3371-803-1 HOLDER (CF-MB) SUB ASSY (RED) (AEP, UK, E) 11 X-3371-804-1 HOLDER (CF-MB) SUB ASSY (BLUE) (IT, EA) 11 X-3371-805-1 HOLDER (CF-MB) SUB ASSY (BLUE) (IT, EA) 11 X-3371-806-1 HOLDER (CF-MB) SUB ASSY (GREEN) (IT, EA) 11 X-3371-807-1 HOLDER (CF-MB) SUB ASSY (RED) (IT, EA) 11 X-3371-820-1 HOLDER (CF-MB) SUB ASSY (BLACK) (EE) 11 X-3371-821-1 HOLDER (CF-MB) SUB ASSY (BLUE) (EE) 11 X-3371-822-1 HOLDER (CF-MB) SUB ASSY (GREEN) (EE) 11 X-3371-823-1 HOLDER (CF-MB) SUB ASSY (RED) (EE) 12 3-933-649-01 KNOB (M/B) 15 3-933-685-01 CABINET (FRONT) (CF-O) (BLACK) (AEP, UK, E, IT, EE, EA) 15 3-933-685-11 CABINET (FRONT) (CF-O) (BLUE) (AEP, UK, E, IT, EE, EA) 15 3-933-685-21 CABINET (FRONT) (CF-O) (GREEN) (AEP, UK, E, IT, EE, EA) 15 3-933-685-31 CABINET (FRONT) (CF-O) (RED) (AEP, UK, E, IT, EE, EA) 15 3-933-685-51 CABINET (FRONT) (CF-O) (BLACK) (US, CND) 15 3-933-685-61 CABINET (FRONT) (CF-O) (BLUE) (US, CND) 15 3-933-685-71 CABINET (FRONT) (CF-O) (GREEN) (US, CND) 15 3-933-685-81 CABINET (FRONT) (CF-O) (RED) (US, CND) 2. ACCESSORIES & PACKING MATERIALS ¥ Abbreviation IT : Italian model EE : East European model FR : French model ¥ Abbreviation CND : Canadian model IT : Italian model EE : East European model EA : Saudi Arabia model FR : French model 16 12 3-939-091-01 KNOB (M/B) (BLACK) 12 3-939-091-11 KNOB (M/B) (OTHERS) 15 3-937-353-01 CABINET (FRONT) (CF-O) (BLACK) (US,E) 15 3-937-353-81 CABINET (FRONT) (CF-O) (OTHERS) (US,E) 15 3-937-353-41 CABINET (FRONT) (CF-O) (BLACK) (AEP, FR, IT, EE) Page WM-FX123 WM-FX163 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark ¥ Items marked Ò*Ó are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. Ref. No. Part No. Description Remark 1-505-521-11 HEADPHONE (MD-023) 3-861-487-11 MANUAL, INSTRUCTION (ENGLISH) (US) 3-859-487-21 MANUAL, INSTRUCTION (FRENCH) (FR) 3-861-487-31 MANUAL, INSTRUCTION (ENGLISH, DANISH, GERMAN, SPANISH, DUTCH, SWEDISH, ITALIAN, PORTUGUESE) (AEP, IT, EE) 3-859-487-41 MANUAL, INSTRUCTION (ENGLISH, DANISH, GERMAN, SPANISH, DUTCH, SWEDISH, ITALIAN, PORTUGUESE) (AEP)3-859-487-61 MANUAL, INSTRUCTION (SPANISH, PORTUGUESE) (E) *3-008-925-01 CUSHION (UPPER) (US, AEP, FR, IT) *3-008-926-01 CUSHION (LOWER) (US, AEP, FR, IT) X-3372-629-2 CLIP, BELT ASSY Ref. No. Part No. Description Remark
