Sony wm ex 372 service manual
This is the 18 pages manual for sony wm ex 372 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony wm ex 372 service manual (Ocr-read)
Page 1
Ð 2 Ð TABLE OF CONTENTS 1. GENERAL ................................................................... 3 2. DISASSEMBLY ......................................................... 4 3. MECHANICAL ADJUSTMENTS ....................... 8 4. ELECTRICAL ADJUSTMENTS ......................... 8 5. DIAGRAMS 5-1. Block Diagram ................................................................ 9 5-2. Printed Wiring Board ...................................................... 11 5-3. Schematic Diagram ......................................................... 13 6. EXPLODED VIEWS ................................................ 16 7. ELECTRICAL PARTS LIST ............................... 19Flexible Circuit Board Repairing ¥ Keep the temperature of the soldering iron around 270 ûC dur- ing repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ¥ Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be dam- aged by heat.
Page 2
Ð 3 Ð SECTION 1 GENERAL This section is extracted from instruction manual.
