Page 2

WM-29/A12/B12

SECTION 1
DISASSEMBLY

[2] Rear Cabinet Removal
Location and shape of claws

The symbols (9-0) show the order to uncouple the
linkage of the claw, and names of the parts.

0 insert a precision screwdriver (width: 2.0mm) into the
© Cassette HolderAﬂy slit of front cabinet, lift the front cabinet as shown in
the figure for making a clearance ( 9 ).

0 Insert a wedge in the clearance.

Note: Follow the disassembly procedure the numerical order given.

1' cl: Precision Screwdrivers ( G) , width 0.8mm, lAmm, and 2.0mm)
Adhesive tape 1-2cm
Wedge (hand 'madel

Material . . . soft plastic (such as PVC) etc.
Sizes are for the reference.

<2: G!
Emm~ -- E 2mm /
S
- - 0.3mm

3mmA

6 Insert a precision screwdriver (width: 20mm), and lift
[1} Cassette Holder Removal the front cabinet so that the claw (3 comes off.

Coil Spring

Open the cassette holder.

OWhile pressing the edge of the cassette holder, pull up it
in order to take off the cassette holder.

OTake off the end of coil spring with a precision screw-
driver (width: 0.8mm).
