Sony tmr rf 940 r service manual
This is the 14 pages manual for sony tmr rf 940 r service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony tmr rf 940 r service manual (Ocr-read)
Page 1
Ð 2 Ð Notes on chip component replacement ·Never reuse a disconnected chip component. ·Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing ·Keep the temperature of the soldering iron around 270 ûC during repairing. ·Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ·Be careful not to apply force on the conductor when soldering or unsoldering This section is extracted from instruction manual. SECTION 1 GENERAL
Page 2
Ð 3 ÐÐ 4 Ð SECTION 2 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. CABINET (UPPER) ASSÕY 4 two claws 2 two claws 4 two claws 3 cabinet (upper) ass y 5 TX board 1 two screws (P2.6 ´ 10)
