Sony tmr rf 415 r service manual
This is the 10 pages manual for sony tmr rf 415 r service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony tmr rf 415 r service manual (Ocr-read)
Page 1
2 TMR-RF415R SECTION 1 GENERAL This section is extracted from instruction manual. DC IN 9V OFF ON FILTER NOISE 123CHANNEL R BAL AUDIO IN Setting up the transmitter 1 Connect the transmitter to audio/video equipment. Select one of the hookups below depending on the jack type:ATo connect to a headphones jack Transmitter Left channel (white) Right channel (red) Unimatch plug adaptor (supplied) CD Walkman, MD Walkman, WALKMAN*, VCR, etc.to headphones jack (stereo mini jack) Connecting cord (supplied)to AUDIO IN A jacks to headphones jack (stereo phone jack) Notes on chip component replacement - Never reuse a disconnected chip component. - Notice that the minus side of a tantalum capacitor may be damaged by heat.
Page 2
3 TMR-RF415R SECTION 2 DISASSEMBLY 2-1. CABINET (UPPER) 2-2. TX-BASE BOARD 1 Four screws (P 2 × 8) Cabinet (upper) 2 2 TX-BASE board Cabinet assy, lowe r 1 Note :Follow the disassembly procedure in the numerical order given.
