Introduction 2EN Welcome! Welcome to the world of the DAT tape- corder! Your DAT tape-corder has the following features, they will be helpful for you to enjoy it to the full. ¥Superb DAT sound quality with excellent frequency response, low noise, and lack of distortion. ¥Easy DAT operation with high speed fast- forward/rewind and cue/review. ¥Long-time recording in the LP mode using four LR6 (size AA) alkaline batteries. ¥Adjustable (automatic/manual) recording level to suit every recording condition. ¥Rec mute function that makes a four- second blank automatically. ¥Date function that stamps date and time during recording. ¥LCD display that indicates the current operating mode and the battery power status, etc. ¥Digital-to-digital recording compatibility with CD/MD players or BS/CS tuner, etc. ¥Three sampling frequencies (48/44.1/32 kHz) that support high quality digital recording. Notes on recording ¥ This tape-corder is not designed for business or commercial use. Never attempt to modify or tamper the tape-corder so that it can be connected to other business or commercial audio equipment. Do not use this tape-corder for data storage. ¥ Check and make sure that the recording operation is not malfunctioning prior to recording important materials. ¥ In no event shall Sony be liable for any direct, indirect, consequential or incidental damages arising from the malfunction of the recording operation of this tape-corder. ¥ Observe the relevant regulations on copyright relating to your collection of recordings. Unauthorized public performance, broadcasting and duplication of a recorded material for commercial purposes are a violation of applicable laws. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. OWNERÕS RECORD The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. TCD-D8 Serial No. WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Ñ Reorient or relocate the receiving antenna. Ñ Increase the separation between the equipment and receiver. Ñ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Ñ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.
