Sony tc tx 101 service manual
This is the 30 pages manual for sony tc tx 101 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony tc tx 101 service manual (Ocr-read)
Page 2
Ð 3 Ð P707, 909 PFJ-1 (Power Supply jig) POWER SWConnector Cable 17P (supplied with set)set Conversion Board (J-2501-144-A) SYSTEM CONTROL PowerFunction SECTION 1 SERVICE NOTE 1-1. SUPPLYING POWER DURING SERVICING This equipment cannot operate without using a separate power supply. Connect this set to the HCD-101. To apply power set the SYSTEM POWER switch of HCD-101. When other units are not available use the PFJ-1 power supply jig. When using the PFJ-1, press the POWER switch of the conversion board to turn on the power. ¥ Connection Diagram * When checking the recording function of TC-TX101, select any function other than TAPE using the Function key of the conversion board before check.
