Page 1

TC-D5III

SERVICE MANUAL AEP Model

UK Model
E Model
Australian Model

East European Model

' This set is the deck section in LBT-DSO7/D507CD/DSO7CDM.

Dolby noise reduction manufactured under license from

Model Name Using

Dolby Laboratories Licensing Corporation. TC-HI 600
"DOLBY" and the double-D symbol [x] are trademarks of Similar Mechanism
Dolby Laboratories Licensing Corporation.
Tape Transport DECK A : TOM-1 90RAI 2C
Mechanism Type DECK B : TCM-I QORBZZC
SPECIFICATIONS
Recording system 4-track 2-channel stereo
Frequency response DOLBY NR OFF

With Type (V cassette

(Sony METAL-ES)
30 Hz to 15 kHZ (:3 dB)

With Type II cassette (Sony UX-S)
40 Hzto 14 kHZ (:3 dB)

With Type | cassette (Sony HF-S)
40 Hzto 14 kHZ(:3 (18)

Wow and flutter :02 % (DIN)
Weight Approx. 3.4 kg
Dimensions Approx. 355 \ tat x 304 mm

(w/h/d. Including projections)
DeSign and specmcations are subject to change without notice.
Note

This appliance conforms with EEC Directive 87/308/EEC regarding
interference Suppression,

CASSETTE DECK
ONYFD

Page 2

TC-DSO7

TABLE OF CONTENTS
SECTION 1, GENERAL ................................................ 3
SECTION 2, DISASSEMBLY ............................................. 4
SECTION 3. MECHAN|CAL ADJUSTMENTS ----------------------- 6
SECTION 4. ELECTRICAL ADJUSTMENTS ------------------------- 6

SECTION 5 DIAGRAMS

5-]. Circuit Boards Location

5-2. Semiconductor Lead Layouts ------------------------------ 10
5»3 Prinlcd wiring 8011de ....................................... ] 1
54, Schematic Diagrams ....................................... 15

SECTION 6. EXPLODED VIEWS

5.]. OverallsecfiOn ............................................... 19
6.2. From Panc| Section .......................................... 20
6-3. Mechanism-l Section --------------------------------------- Z]
6-4. Mechanism-2 Section -------------

SECTION 7. ELECTRICAL PARTS LIST
