TA-V902

MODEL IDENTIFICATION TABLE OF CONTENTS

- Specification Labels -
Section Title Page
Specifications ................................. 1
W Model Identification ~~~~~~~~~~~~~~~~~~~~~~~~~~~~ 2

INTEGRATED STEREO AMPLIFIER
WW 1_ GENERAL ............................. 3

2. DIAGRAMS

SERIAL No. 2-1. Printed Wiring Boards
MADE IN JAPAN - Function, D/A Convener Section - ~~~~~~ 6
2-2. Schematic Diagram
- Function, D/A Convener Section - ------- 9
AEP M°deI3 AC: 22°V~5W50HZ 2-3. Schematic Diagram - Main Section -- ------- l4
Rana" Model: AC: 220V~50/60HZ 24 Printed Wiring Boards - Main Section - ~ - 19
UK Model: AC: 240 V ~50/60 Hz
E, Saudi Arabia Model: AC: 120/220/240V~50/60HZ 190W 3' EXPLODED VIEWS .................... 25
WG Model: AC: 220V~50l60Hz
4. ELECTRICAL PARTS LIST ~~~~~~~~~~~~ 27

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BV MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
