Sony ta v 702 service manual

This is the 15 pages manual for sony ta v 702 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 15
sony ta v 702 service manual

Extracted text from sony ta v 702 service manual (Ocr-read)


Page 2

MODEL IDENTIFICATION
~8pecification Label-

West Germany Model:

SONYo MODEL no, TA-V702 SONYo MODEL No, TA-V702

INTEGRATED STEREO AMPLIFIER INTEGRATED STEREO AMPLIFIER
SYSTEM LBT-V702
AC : 220V~50/60Hz

5

SERIAL NOI SERIAL NO.
MADE IN JAPAN MADE IN JAPAN

AEF Model : AC : 220V~50/€0HZ
Italian Model : AC : 220V~50/60Hz
UK Model : AC: 240V~50/60Hz
E, Saudi Arabia Model : AC: IZOV/ZZDV/240V~50/60HZ 175W

SAFETY-RELATED COMPONENT WARNINGII

COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
