Sony ta n 110 service manual

This is the 11 pages manual for sony ta n 110 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 11
sony ta n 110 service manual

Extracted text from sony ta n 110 service manual (Ocr-read)


Page 2

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.

SAFETY CHECK-OUT

After correcting the original service problem,
perform the following safety check before releasing
the set to the customer:

Check the antenna terminals, metal trim, metallized
knobs, screws, and all other exposed metal parts for
AC leakage, Check leakage as described below.

LEAKAGE TEST

The AC leakage from any exposed metal part to
earth ground and from all exposed metal parts to any
exposed metal part having a return to chassis, must
not exceed 0.5 mA (500 microampers). Leakage
current can be measured by any one of three
methods

1. A commercial leakage tester, such as the
Simpson 229 or RCA WT-54OA. Follow the
manufacturers instructions to use these instru-
merits.

2, A battery-operated AC milliammeter. The Data

Precision 245 digital multimeter is suitable for
this job.

3 Measuring the voltage drop across a resistor by
means of a VOM or battery-operated AC volt-
meter. The limit indication is 0.75 V, so
analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa
SH-63Trd are examples of a passive VOM that
is suitable. Nearly all battery operated digital
multimeters that have a 2 V AC range are
suitable. (See Fig. A)

To Exposed Metal
Parts on Set

/ AC
voltmeter

0.15M [ g 1.5m
_ I0. 75 w
._l

'7' Earth Ground

Fig. A. Using an AC voltmeter to check A C leakage.

MODEL IDENTIFICATION
- Specification Label -

SONYo

MODEL NO. TA-N110

STEREO POWER AMPLIFIER

US model: AC: 120V 60Hz 110W
AEP, WG model: AC: 220V~50/60H2 140W
UK model: AC: 24OV~50/60Hz 140W

E model: AC: 120, 220, 240V~50/60Hz 140W

(WG model: West Germany)

_2__
