– 2 – TABLE OF CONTENTS 1. GENERAL Location of Controls ....................................................... 3 2. DISASSEMBLY ......................................................... 4 3. DIAGRAMS 3-1. Notes for Printed Wiring Boards and Schematic Diagrams ................................................ 6 3-2. Printed Wiring Board – MAIN Section – ...................... 7 3-3. Schematic Diagram – MAIN Section – .......................... 9 3-4. Printed Wiring Boards – PANEL Section – .................. 11 3-5. Schematic Diagram – PANEL Section – ....................... 13 3-6. Printed Wiring Boards – POWER Section – ................. 15 3-7. Schematic Diagram – POWER Section – ..................... 16 3-8. IC Pin Function Description ........................................... 18 4. EXPLODED VIEWS ................................................ 19 5. ELECTRICAL PARTS LIST ............................... 21 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY.
Page 2
– 3 – SECTION 1 GENERAL This section is extracted from instruction manual. LOCATION OF CONTROLS Front Panel 1 I/u (POWER) button 2Remote control sensor 3INPUT SELECTOR switch 4VOLUME control 5EON LINK button (TA-FE520R only) 6PHONES jack 7SPEAKERS switch 8BASS control 9TREBLE control 0BALANCE control !¡LOUDNESS button !™SOURCE DIRECT button !£TAPE MONITOR button (TA-FE520R only) Rear Panel
