Sony ta fa 5es fa7es int service manual

This is the 30 pages manual for sony ta fa 5es fa7es int service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 30
sony ta fa 5es fa7es int service manual

Extracted text from sony ta fa 5es fa7es int service manual (Ocr-read)


Page 2

TABLE OF CONTENTS

Section M Page
Specifications .................................. 1
1. GENERAL
Location of Col-[015 ...................... 3

2. DISASSEMBLY ......................... 4
3. ELECTRICAL ADJUSTMENT ----------- 7
4. DIAGRAMS
4~1. IC Pin Function Description ---------------- 3
4-2. Schematic Diagram ~~~~~~~~~~~~~~~~~~~~~~~ 11
4-3. Primed Wiring Boards

- MAIN Section - ......... 15
4-4. Printed Wiring Boards

- CONTROL Section ~ ----- 19
5. EXPLODED VIEWS -------------------- 23
6. ELECTRICAL PARTS LIST ------------ 27

SAFETY-RELATED COMPONENT WARNINGII

COMPONENTS IDENTIFIED BY MARK A OR DOI'I'ED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
