General

System Preamplifier section: Low-noise high
gain-NAB type equalizer amplifier,

passive type direct tone control

Power amplifier section: Pure-

complementary SEPI power amplifier,

MOS FET power transistor for final

stage

220 - 230 V AC, 50/60 Hz

Scandinavian countries, Switzerland,

Spain and Portugal: 220 W

Other countries: 300 W

Approx. 430 x150 x 375 mm (w/h/d)

, (t7x57/8xi43/4inches)

Mass Approx. 120 kg (26 lbs 7 oz)

Accessories supplied Remote Commander RM-S703 (1)
Sony batteries SUM-3 (NS) (2)

Power requirements
Power consumption

Dimensions

Design and specifications are subject to change without notice.

Note

This appliance conlorms with EEC directive 87/308/EEC regarding
interference suppression.

MODEL IDENTIFICATION
- Specification Label -

SONYO

MODEL NO. TA-FSOGES

m

49664584013 :AEP1 model
4-966-384-1EI :AEP2 model
4-966-385-0D :German model

Note:

There are two type of AEP models which are depend

on countries.

AEPZ : Model for Scandinavian countries,Switzerland,
Spain and Portugal.

AEPI : Model for other European countries.

TABLE OF CONTENTS


mm m .ageP
1. GENERAL ............................... . 3
2. ELECTRICAL ADJUSTMENT ................................ 4
3. DIAGRAMS
3-1. Circuit Boards Location . 5
3-2. Block Diagram
3-3. Schematic Diagram
3-4. Printed Wiring Boards - Input Section -
3-5. Printed Wiring Boards - Main Section -
3»6. Semlconductor Lead Layouts ........................
37 IC Pin Function

ICBOS System Controller (M50720-3588P).....,............ 23
4. EXPLODED VIEWS
44. Front Panel Section..
4-2. Sub Chassis Section .25
4-3. Main Chassis Section ........................................ .26
5, ELECTRICAL PARTS LIST ................................... 27

SAFETY-RELATED COMPONENT WARNING I!

COMPONENTS IDENTIFIED BY MARK A OR DOTTED

LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE

OPERATION. REPLACE THESE COMPONENTS WITH
SONV PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.

_2_
