2 STR-DE875/DE975 Harmonic distortion 0.5 % (50 mV/m, 400 Hz) Selectivity At 9 kHz: 35 dB At 10 kHz: 40 dB c) You can change the AM tuning interval to 9 kHz. After tuning in any AM station, turn off the receiver. Hold down the PRESET TUNING + button and press the ?/1 button. All preset stations will be erased when you change the tuning interval. To reset the scale to 10 kHz, repeat the procedure. Video section InputsVideo: 1 Vp-p 75 ohms S-video: Y: 1 Vp-p 75 ohms C: 0.286 Vp-p 75 ohms OutputsVideo: 1 Vp-p 75 ohms S-video: Y: 1 Vp-p 75 ohms C: 0.286 Vp-p 75 ohms General SystemTuner section: PLL quartz-locked digital synthesizer system Preamplifier section: Low-noise NF type equalizer Power amplifier section: Pure-complementary SEPP Power requirements 120 V AC, 60 Hz Power consumption US MODEL : STR-DE975: 270 W In standby condition: 0.9 W STR-DE875: 260 W In standby condition: 0.9 W Canadian MODEL : Others :STR-DE975: 350 VA In standby condition: 0.9 W STR-DE875: 340 VA In standby condition: 0.9 W AC outlets 2 switched, total 120 W/1A Max Dimensions430 × 157.5 × 369 mm (17 × 6 1/8 × 14 4/8 in.) including projecting parts and controls Mass (Approx.) 9.5 kg (20 lbs. 16 oz.) Supplied accessories Design and specifications are subject to change without notice. FM tuner section Tuning range 87.5 - 108.0 MH Antenna terminals 75 ohms, unbalanced Intermediate frequency 10.7 MHz SensitivityMono: 18.3 dBf, 2.2 µV/75 ohms Stereo: 38.3 dBf 22.5 µV/75 ohms Usable sensitivity 11.2 dBf, 1 µV/75 ohms S/NMono: 76 dB Stereo: 70 dBHarmonic distortion at 1 kHz Mono: 0.3% Stereo: 0.5% Separation45 dB at 1 kHz Frequency response 30 Hz - 15 kHz +0.5/–2 dB Selectivity60 dB at 400 kHz AM tuner section Tuning range With 10-kHz tuning scale: 530 - 1710 kHz c) With 9-kHz tuning scale: 531 - 1710 kHz c) AntennaLoop antenna Intermediate frequency 450 kHz Usable sensitivity 50 dB/m (at 1,000 kHz or 999 kHz) 50 dB/m (at 999 kHz) S/N54 dB (at 50 mV/m) -FM wire antenna (1) -AM loop antenna (1) -R6 (size-AA) batteries (2) -US, Canadian model only -Audio/video/control S connecting cord (1) -Control S connecting cord (1) - STR-DE975 only - Remote commander RM-PP505L (remote) (1) -STR-DE875 : US, Canadian, E, Malaysia, - Remote commander RM-PP505 (remote) (1) EQBASS: 99 Hz~1.0 kHz (21 steps) MID: 198 Hz~10 kHz (37 steps) TREBLE: 1.0 kHz~10 kHz (23 steps) Gain levels: ±10 dB, 1dB step Sampling Frequency 48 kHz (TV/SAT, MD/DAT*, MD/TAPE** OPTICAL IN) 96 kHz (DVD/LD OPTICAL IN, COAXIAL IN) * STR-DE975 only ** STR-DE875 only OutputsMD/DAT*, MD/TAPE** (OUT); VIDEO 1, VIDEO 2: (AUDIO OUT): Voltage: 250 mV, Impedance: 10 kilohms SUB WOOFER: Voltage: 2 V Impedance: 1 kilohms PHONES: Accepts low- and high-impedance headphones Inputs (Digital) DVD/LD (coaxial): Sensitivity: – Impedance: 75 ohms S/N: 100 dB (A, 20 kHz LPF) DVD/LD, TV/SAT, MD/DAT*, MD/TAPE** (Optical): Sensitivity: – Impedance: – S/N: 100 dB (A, 20 kHz LPF) Singapore, Chinese, Australian model only -STR-DE875 : AEP, UK model only - Commander, standard RM-U305A (remote) d) You can change the AM tuning interval to 10 kHz. After tuning in any AM station, turn off the receiver. Hold down the TUNING + button and press the 1/u button. All preset stations will be erased when you change the tuning interval. To reset the scale to 9 kHz, repeat the procedure. AEP, UK MODELS : 531 - 1602 kHz E MODEL : 530 - 1610 kHz (10 kHz step) d) 531 - 1602 kHz (9 kHz step) d) Others : 531 - 1602 kHz (9 kHz step) US, Canadian MODELS : AEP, UK MODELS : Others : AEP, UK MODELS : 35 dB Others :US, Canadian MODELS : AEP, UK MODELS : E MODEL :230 V AC, 50/60 Hz 120/220/240 V AC, 50/60 Hz Australian MODEL : 240 V AC, 50 Hz Others : 220-230 V AC, 50/60 Hz 220 W In standby condition: 0.9 W US, Canadian MODELS : AEP, UK MODELS : 1 switched, max 100 W E, Chinese MODELS : Others :2 switched, total 100 W max 1 switched, total 100 W max
