Sony str de 445 service manual
This is the 48 pages manual for sony str de 445 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony str de 445 service manual (Ocr-read)
Page 1
2 Parts No. MODEL IDENTIFICATION - BACK PANEL - MODEL PARTS No. DE545: US model 4-226-802-0s DE545: Canadian model 4-226-802-1s DE545: Australian model 4-226-802-2s DE545: E, PX model 4-226-802-3s DE545: Malaysia, Singapore model 4-226-802-4s DE545: Chinese model 4-226-802-5s DE545: AEP, UK, CIS model 4-226-802-6s DE545: Taiwan model 4-226-802-7s DE445: US model 4-226-808-0s DE445: Canadian model 4-226-808-1s DE445: AEP, UK model 4-226-808-2s DE445: CIS model 4-226-808-3s SE501: US model 4-227-063-0s AM tuner sectionTuning range With 10-kHz tuning scale: 530 – 1,710 kHz d) With 9-kHz tuning scale: 531 – 1,710 kHz d) Antenna Loop antenna Usable sensitivity 50dB/m (at 1,000kHz or 999kHz) S/N 54dB (at 50mV/m) Harmonic distortion 0.5% (50mV/m, 400kHz) Selectivity At 9kHz: 35dB At 10kHz: 40dB d) You can change the AM tuning interval to 9kHz. After tuning in any AM station, turn off the receiver. Hold down the TUNING + button and press the @/1 button. All preset stations will be erased when you change the tuning interval. To reset the scale to 10 kHz, repeat the procedure. Video sectionInputs Video: 1Vp-p 75Ω S-video*: Y: 1Vp-p 75Ω C: 0.286Vp-p 75Ω Outputs Video: 1Vp-p 75Ω S-video*: Y: 1Vp-p 75Ω C: 0.286Vp-p 75Ω * STR-DE545 and STR-SE501 only. GeneralSystem Tuner section: PLL quartz-locked digital synthesizer system Preamplifier section: Low-noise NF type equalizer Power amplifier section: Pure-complementary SEPP Power requirements US, Canadian model: 120V AC, 60Hz Taiwan model: 110V AC, 60Hz Chinese, Singapore, Malaysia model: 220 – 230V AC, 50/60Hz AEP, UK, CIS model: 230V AC, 50/60Hz Australian model: 240V AC, 50/60Hz E, PX model: 120V or 220V or 240V AC, 50/60Hz Power consumption STR-DE545/SE501: US model: 190W AEP, UK model: 220W STR-DE445: US model: 185W AEP, UK model: 160W AC outlets (STR-DE545 and STR-SE501 only) US model: 1switched, total 120W/1A Max EXCEPT US: 1switched, max 100W Dimensions 430 × 303 × 157 mm (17 × 12 × 6 1/4 inches) including projecting parts and controls Mass (Aporox.) STR-DE545: 7.9kg (17 lbs. 7 oz) STR-DE445: 7.7kg (16 lbs. 16 oz) STR-SE501: 8.2kg (18 lbs. 2 oz) Supplid accessories FM wire antenna (1) AM loop antenna (1) R6 (size-AA) batteries (2) STR-DE545 and STR-SE501 only Remote Commander RM-PP404 (remote) (1) Operating instructions of the remote (1) Operating instructions of CONTROLA1 II (1) STR-DE445 only Remote Commander RM-U304 (remote) (1) Design and specifications are subject to change without notice.
Page 2
