STR-DE425

SERVICE MANUAL US Model

Canadian Model
AEP Model

UK Model
E Model
Australian Model

3 Chinese Model

Manufactured under license from Dolby Laboratories
Licensing Corporation.

DOLBY, PRO LOGIC" and the double-D symbol are
trademarks of Dolby Laboratories Licensing Corporation.

SPECIFICATIONS
Amplifier section Outputs TAPE/MD REC OUT: AM tuner section
Power output Voltage: 150 mV. Tuning range 531 - 1602 kHz
Stereo mode (DIN 1 kHz, 4 ohms) Impedance: 10 kilohms Aerial Loop aerial
90 w + 90w VIDEO AUDIO OUTE Usable sensitivity 50 (Elm (at 999 kHz)
Surround (DIN 1 kHz. 4 ohms) Wilma: 150 mV~ SIN 54 rim! 50 mV/m)
mode Prom; 90W/ch Impedance: 10 kilohms Harmonic 0.5%(50 mV/m, 4001-12)
Calm: 90w WOOFER/MIX AUDIO distant
(oniy in PRO LOG [C MODE) OUT- V°llag°= 2? Selectivity 35 dB
REAR: (DIN 1 kHZ, Sohms) 45 chh mPed-nw 10 mm _
51va Front: 90 chh PHONES: Accepts 161" and high Video section
INPUT * mode (DIN 1 kHz. 4 ohms) impedfim headphms Input VIDEO I. 2, TV:
Centre: 90 w (DIN 1 kHz. 4 ohms) _ 1 vap 75 ohms
Rear: 45 Web (DIN 1 kHz, 3 ohms) Mmmz W1 11"- otitput VIDEO 1. 2. MONITOR:
Frequency PHONO: RIAA BASS BOOST +1043 9 70 H1 1 Vprp 75 ohms
mm eqmmon We :05 an TONE 18113 at 100 Hz and 10 kHz
TV 1 LD. CD. TAPE/ MD. General
vao, 51/DVD mum FM tuner section symm Me, section; PLL
1on - 50km eidB 1\mims range 87-5 - 108-0 MHz quartz-10cm digital
Input Aerial terminals 75 ohms, unbalanced syntheslner system
-'4 . . Sensitivity Mono: 18.3 dBL 2.2uv n5 ohms ~ to:
Sammy Fem"? 5? Stereo: 33.3 ($131 22.5 uv n5 Ohms Marni-21:33:; type
(Wegh'mg Usable sensitivity 1112 (13". 1v n5 ohms (II-IF) Epualizer
{lewfim 1 5 Mom: 75 3 Power amplifier section:
-41%- Stereo: 70dB Pure-complimentary
PHONO 2.5mV so 74 an Harmonic Mona: 03 95> 513p}:
(MM) Idiot-tins 72 d8 distortion at Stereo: 0.5 % Power 230 V AC. 50/60 Hz
(A. 2.5 mV) (Hz requirements
CD Separation 45dE at 1 kHz mm 230 w
5. 1/bv1) zoo inv 13:93:? 3° 1 15 32° 5:13 consumption .
INFUT 1 > . AC outlets Swnched 100 W
___.__ 50 82 dB Selectmty 60 dB 31400 kHz (map, for me uK.
TAPE/MD. mourns 32 413% model)
TVILD, 150 mV (A1 150 mV)
VIDEO

______7. ,
- Continued on next page -

FM STEBEOIFM-AM RECEIVER
ONYE

MICFIOFILM

Page 2

Dimensions 430 x 145 x 295 mm
Mussmpprox.) STR-DEAZS: 7.9 kg
Supplied FM wire aerial (1)
accessories AM loop aerial (1)
Remote controller (remote) (1)
Size AA (R6) hatteries (2)

Design and specifications are subject to change without notice.
Specifications indicated are measured at 230 VAC, 50 Hz

SAFETY CHECK-OUT

After correcting the original service problem, perform the
following safety checks before releasing the set to the customer:
Check the antenna terminals, metal trim, metallized knobs, screws,
and all other exposed metal parts forAC leakage. Check leakage as
described below.

LEAKAGE

The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers).
Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers instructions to use these
instruments.

2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The limit" indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples of
a passive VOM that is suitable, Nearly all battery operated
digital multimeters that have a 2V AC range are suitable. (See
Fig. A)

n: EmosedMeta/
Pam on Set
AC
0.15uF:: $1.510 my
': Earth Ground

Fig. A. UsinganAC voltmeterto checkAC leakage.

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARKA OR DOTI'ED LINEWITH
MARK A ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

TABLE OF CONTENTS
1. GENERAL ............................................................... 3

2, TEST MODE ............................................................ 4

3. DIAG RAMS
3.1, Circuit Boards Location .............................................
3.2. Block Diagram ...............................
3-3. Schematic Diagram - Display Section -
3-4. Printed Wiring Board - Display Section -
3-5. Schematic Diagram - Power Section -
3-6. Printed Wiring Board - Power Section -
3»7. Printed Wiring Board - Main Section -
3-8. Schematic Diagram - Main Section (1/3) -
3-9. Schematic Diagram ~ Main Section (2/3)
3-10. Schematic Diagram 7 Main Section (3/3)
3-11. IC Pin Function Description
3-12. IC Block Diagrams -----------

. EXPLODED VIEWS
4-1. Front Panel Section ..
4-2. Chassis Section ------

5. ELECTRICAL PARTS LIST ------------------------------- 31
