Sony str de 315 str de 415

Page 2

Selecitivity 60dB at 400kHz

AM tuner section
Tuning range 522 - 1611 kHz

Aerial Loop aerial

Usable SOdB/m (at 999kHz)
sensitivity

SIN 54dB (at SOmV/m)
Harmonic 0.5% (SOmV/m,
distortion 400Hz)
Selectivity 35dB

General

system Tuner section : PLL

quartz-locked digital
synthesizer system
Preamplifier section :
Low-noise NF type
equalizer
Power amplifier section :
Pure-complimentary

SEPP
Power 230VAC. 50/60Hz
requirements
Power STR-DE415 : 175W

consumption STR-DE315 : 175W

AC outputs Switched 100W
(except for the UK.
model)

Dimensions 430 x 145 x 295mm

Mass (Approx.) 6.4kg

Supplied FM wire aerial (l)
accessories AM loop aerial (1)
Remote controller
(remote) (1)
Size AA (R6) batteries (2)
Scan adaptor (1)

Design and specifications are subject to change without notice.

SAFETY-RELATED COMPONENT WARNING I!

COMPONENTS IDENTIFIED BY MARKAOR DOTI'ED LINEWITH
MARK A ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
