Page 2

Amplifier
DIN power output 50 W + 50 W (6 ohms. al1 kHz)
COHIIHUOUS RMS power output
60 W + 60W (6 ohms. at1 kHz, 5%
THD)

Musrc power output 90 W + 90 W (6 ohms)

I Input Jack lype Sensitivny Impedance

I VIDEO IN Phone 1 300 mV I 47 kohms

I PHONO lN Phono i 3 mV I 47 kohms

I Output I Jack type Impedance

I SURROUND | Phono 1 Accepts speakers 0116 ohms

I SPEAKER

I HEADPHONES Stereophone Accepts headphones ol 8 ohms

2 or more

Frequency response VIDEO: 15 Hz to 50 kHz :3 dB

Power requirements 220 - 230 V AC. 50/60 Hz

Power consumption 150 W
Mass Approx. 7.3 kg
Dimensions Approx. 355 X 225 X 330 mm

(w/h/d. including pleeCIIOIlS)

Note on Ceramic FIIter(CF301, A302, 303) Replacement.
(PANEL BOARD : D609, D610)

This set employs two ceramic filters (CF301, A302. 303) which
should have the same color marking to identify their oenler
frequency. therefore FM IF offset adjustment by (*A. *3)
connection is necessary to match the center frequency of the
ceramic filters used with FM inlennediate frequency.

oolor marking

,(
(CF301. 302. 303)

ACFSOZ : (3.1T model

O:short
X :open
Ceramic filter Connection FM intermediate
Color Center frequency *A *5 frequency
mark (MHz) (D610) (m9) (MHZ)

Whlts 10750 X 0 10.750

Red 10.700 X X 10.700

Black 10.650 0 x 10.650

MODEL IDENTIFICATION

- Model Number Portion - STR-A37, D309, D359

S ON Y; MODEL N0.

FM STEREO/FM-AM RECEIVER

AC://

AEP, GY IT, EE, CIS Model: 220-230V~50/60Hz 150W
UK Model: 240V~50Hz
E, AUS, PX Model: 1 10-120V/220-240V~50/60HZ155W

Note:

G model : Germany model

IT model : Italian model

EE model : East European model

AUS model : Australian model

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK A 0R DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB»
LISHED BY SONY.
