Sony st sv 7 service manual
This is the 36 pages manual for sony st sv 7 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony st sv 7 service manual (Ocr-read)
Page 2
3 ST-SV7 1ANTENNA terminal 2SYSTEM CONTROL 1 connector (TO TA-SV7AV) 3SYSTEM CONTROL 2 connector (TO TA-SV7AV) 4SYSTEM CONTROL 3 connector (FROM MCE-SV7) 5OPTICAL IN terminal 6OPTICAL IN terminal (FROM MCE-SV7) 7SYSTEM CONTROL 4 connector (TO TC-S3) 8OPTICAL OUT terminal 9SUB WOOFER OUT jack 0MD IN/OUT jack qaVIDEO (AUDIO) IN jack – Rear Panel – SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION OF CONTROLS – Front Panel – 1 2 3 4 5 6 7 8 0 9 qa Ð Ð + + qk qlw; wa ws wd wf wg wh wj CLOCK/TIMER wh (13, 25, 34) DISPLAY qk (13, 18, 33, 40) ENTER ws (22) IR receptor wj PRESET –/+ wd (22) STEREO/MONO ql (22) TIMER SELECT wg (26, 35) TUNER/BAND wf (22) TUNER MEMORY w; (22) TUNING –/+ wa (22)
