Page 2

ST-Sl 70

MODEL IDENTIFICATION
~Specification Label-

SONYo MODEL NO. ST-Sl70

FM STEREO/FM-AM TUNER

SERIAL NO.
MADE IN JAPAN

Canadian Model 2 AC: 120V 60Hz 10W
E Model : AC : 110~120V/220-240V
50/60Hz 10W

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK & OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL T0 SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.

On salety

- Before connecting the unit to the power source check
that the operating voltage of your unit is the same as
the local power line voltage

Where purchased Operating voltage

Canada 120 V AC, 60 Hz

E Model 110-120 or 220-240 V AC, 50/60
Hz (Adjustable using the voltage
selector at the rear)

VOLTAGE SELECTOR
no-tzov 220-240v

\

V-r

- Should any solid object or liquid fall into the unit,
unplug the unit and have it checked by qualified
personnel before operating it any further.

. Unplug the unit from the wall outlet it it is not to be
used for an extended period of time. To disconnect the
cord, pull it out by grasping the plug. Do not pull the
cord itself.

0 AC power cord must be changed only at the qualified
service shop.

ATTENTION AU COMPOSANT AYANT RAPPORT
A LA SECURITEI

LES COMPOSANTS IDENTIFIES PAR UNE MAROUE A
sun LES DIAGRAMMES SCHEMATIOUES ET LA LISTE
DES PIECES SONT camouEs POUR LA SECURITE
DE FONCTIONNEMENT. NE REMPLACER czs coM-
POSANTS QUE PAR DES PIECES SONY DONT LES
NUMéRos SONT DONNés DANS CE MANUEL ou
DANS LES SUPPLEMENTS PUBLIES PAR soNv.
