Sony ss zx 6 service manual
This is the 4 pages manual for sony ss zx 6 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss zx 6 service manual (Ocr-read)
Page 1
2 SS-ZX6 NOTE: -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Accessories are given in the last of this parts list. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 4-999-101-01 SCREW, HEXAGON HOLE TAPPING 2 A-4713-950-A TWEETER ASSY, HORN 3 4-874-614-71 SCREW 4 4-227-036-01 BRACKET 5 A-4713-949-A PANEL ASSY, FRONT SP1 1-504-399-21 SPEAKER (16cm) (WOOFER) SP2 1-529-956-11 SPEAKER (2.5cm) (TWEETER) SP3 1-504-220-21 SPEAKER (16cm) (WOOFER) #1 7-685-661-19 SCREW +BVTP 4X12 TYPE2 N-S EXPLODED VIEW AND PARTS LIST not supplied 4 3 5 3 2 1 #1 #1 SP3 SP2 SP1 not supplied
Page 2
3 SS-ZX6 MEMO
