SSX-JN66 2 EXPLODED VIEW -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. -The mechanical parts with no reference number in the exploded views are not supplied. -Accessories are given in the last of the electrical parts list. NOTE: --XX and -X mean standardized parts, so they may have some difference from the original one. -Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑↑ Parts Color Cabinet's Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1A-4714-427-A SYSTEM (L) ASSY (Lch) 1A-4714-428-A SYSTEM (R) ASSY (Rch) 2A-1058-015-A PANEL (L) ASSY, FRONT (Lch)2A-1058-017-A PANEL (R) ASSY, FRONT (Rch) 34-254-252-01 FOOT (FRONT) 44-254-253-01 FOOT (REAR) Note: This is the figure of Lch set. 1 3 4 2 Ver 1.1
Page 2
SSX-JN66 3 MEMO
