Page 1
2 SS-CNP66/MSP66L/MSP66R/MSP66SL/MSP66SR/WMSP66/VE66P ark SS-CNP66/MSP66L/MSP66R/MSP66SL/MSP66SR EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.--XX, -X mean standardized parts, so they may have some differences from the original one. 13 2 3 not suppliednot suppliednot supplied 4 Ve r. 1.1 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 14-986-971-02 SCREW (3.5) 21-694-516-11 TERMINAL, SPEAKER 34-246-231-01 SCREW (3.5X14)4A-1072-247-A OVERALL ASSY (SS-CNP66/MSP66L/MSP66R) 4A-4714-920-A OVERALL ASSY (SS-MSP66SL/MSP66SR)
Page 2
3 SS-CNP66/MSP66L/MSP66R/MSP66SL/MSP66SR/WMSP66/VE66P Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SS-WMSP66 4 5 6 2 31 not supplied #2 #1 1A-4713-822-A OVERALL ASSY 24-243-842-21 GRILLE FRAME 34-998-417-02 SONY EMBLEM (No.5) 41-825-845-11 SPEAKER (20cm)54-244-708-01 FRONT PANEL 64-243-866-01 DUCT PACKING #1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 MM #2 4-235-677-01 SCREW (4X20)(TYPE1), +BVTP
