Extracted text from sony ss vf 300 h service manual (Ocr-read)
Page 2
SS-CNV200H/CNV300H/FCR200H/
FCR300H/SRV200H/SRV300H/ SECTION 1
VF200H/VF300H EXPLODED VIEWS
Ve r. 1 .1
NOTE:
- The mechanical parts with no reference - Accessories are given in the last of this
number in the exploded views are not supplied. parts list.
- Items marked *" are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
1-1. FRONT SPEAKER SECTION
(SS-VFZOOH/VFSOOH)
we
1 6 \y///K\é: i \
not ,
supplied .
/i§< not
V supplied
not .
supplied '
//4
/7
6
2
Ref.No. PartNo. Description Remark Ref.No. PartNo. Description Remark
1 2-109-840-01 FRAME, GRILLE 6 4-986-971-02 SCREW (3.5x10)
X-2022-499-1 PANEL ASSY, FRONT
X-2022-500-1 CABINET ASSY
X-2022-502-1 TW ASSY
X-2022-501-1 BASE ASSY
4-229-966-02 SCREW (4X16)
1-825-912-11 SPEAKER (Scmxi 1 cm)
1-694-516-21 TERMINAL, SPEAKER
macaw
tomxi
