Sony ss v 831 ex service manual
This is the 4 pages manual for sony ss v 831 ex service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss v 831 ex service manual (Ocr-read)
Page 1
2 SS-V831ED EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark NOTE: -The mechanical parts with no reference number in the exploded views are not supplied. -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.--XX and -X mean standardized parts, so they may have some difference from the original one. -Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinets ColorRR SP1not suppliedSP2 SP3 zA not supplied (including zA) 1 2 23 124 12 12 56 7 11 11 10 8 9 1X-4954-548-1 FRAME ASSY (V), GRILLE 24-238-678-01 SCREW, ORNAMENTAL 34-239-114-01 PANEL, FRONT 44-986-971-11 SCREW (3.5) 54-239-118-01 PACKING 61-761-530-11 MAIN BOARD 71-694-516-21 TERMINAL, SPEAKER 84-239-107-01 STAY (V)94-239-106-01 BASE (V) 10 4-222-029-01 SCREW (+P 3.5X14) 11 7-682-145-01 SCREW +P 3X4 12 7-682-150-01 SCREW +P 3X12 SP1 1-825-079-11 SPEAKER (1.9cm) (TWEETER) SP2 1-825-068-11 SPEAKER (5.7cm) (WOOFER) SP3 1-825-068-11 SPEAKER (5.7cm) (WOOFER)
Page 2
3 SS-V831ED MEMO
