SS-VI
SERVICE MANUAL
SPECIFICATIONS
Speaker system
Enclosure type
Full range
Speaker units 10cm, cone tYDe
Bass reflex
Rated impedance 16 ohms
Power handling capacity
MAX. sow
Sensitivity 90 dB(lW, lm)
Frequency range 120 Hz to 20,000 Hz
Dimensions Approx. 120 x 120 x
120 mm (w/h/d)
Weight Approx. 650g per speaken
net
Approx. 1.5kg in shipping
carton
Design and specifications subject to change
without notice
EXPLODED VIEW AND PARTS LIST
Part Hm
I X-4918-308-1
2 4-9l3-333-OI
3 1-635467-l9
4 7-685-159-Il
5 l-574e913-ll
l l-544-432-li
34534154!
4-918-337-01
>lr 4-944-294-01
9-956-267-11
CODED comm)
UNCODED CORD(-)
AEP Model
Description
BOARD ASS BAFFLE 0 Items marked "1" are not stocked since they
CABINET are seldom required for routine service. Some
SCREW +I 4X35 TYPEZ RON-SIIT
SCREW +P 4X8 TYPEZ NON-SUI
CORD. SPEAKER
SPEAKER (IOCM)
ACCESSORY & PACKING MATERIAL
MANUAL. INSTRUCTION
FOOT. RUBBER
lNDlVlDUAL CARTON
Sony Corporation
Audio Group
delav should be anticipated when ordering these
items.
SPEAKER SYSTEM
S O NEG
Engiish
9 1 30447-1
Primed in Japan
©>1991.2
