Sony ss v 531 h service manual
This is the 4 pages manual for sony ss v 531 h service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss v 531 h service manual (Ocr-read)
Page 1
2 SS-V531H EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark NOTE: - The mechanical parts with no reference number in the exploded views are not supplied. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.- -XX and -X mean standardized parts, so they may have some difference from the original one. - Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinets ColorRR 1 X-4954-607-1 FRAME (V) ASSY, GRILLE 2 4-231-872-01 SCREW, ORNAMENTAL 3 4-239-550-01 PANEL, FRONT 4 4-986-971-11 SCREW (3.5) 5 X-4954-610-1 CABINET ASSY 6 1-694-516-21 TERMINAL, SPEAKER 7 7-682-149-04 SCREW +P 3X108 4-239-556-01 COVER 9 4-238-824-01 SCREW 10 4-239-555-01 TW-BASE SP1 1-825-042-11 SPEAKER (2.5cm) SP2 1-825-043-11 SPEAKER (5.7cm) SP3 1-825-043-11 SPEAKER (5.7cm) SP3 SP2 SP1 not supplied not supplied 12 23 4 4 4 5 6 10978
Page 2
3 SS-V531H MEMO
