Sony ss v 331 service manual
This is the 4 pages manual for sony ss v 331 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss v 331 service manual (Ocr-read)
Page 1
2 SS-V331 EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark NOTE: - The mechanical parts with no reference number in the exploded views are not supplied. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - -XX and -X mean standardized parts, so they may have some difference from the original one. - Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinets Color RR 1 X-4954-603-1 FRAME (SR) ASSY, GRILLE 2 4-232-301-12 SCREW (3.5X75) +P, TAPPING 3 4-232-302-01 CATCHER, GRILLE 4 4-232-298-01 BOARD (SR), BAFFLE 5 X-4953-440-1 CABINET (SR) ASSY, SPEAKER 6 1-694-516-21 TERMINAL, SPEAKER 7 4-986-971-11 SCREW (3.5) 8 1-761-413-11 MOUNTED PC BOARD (NETWORK) (E) 9 1-823-042-11 CORD (WITH C) (EXCEPT E) SP1 1-529-974-11 SPEAKER (5.5X11cm) 1 SP1 2 2 3 9 4 8 3 not supplied not supplied not supplied 5 6 7 V er 1.1
Page 2
3 SS-V331 MEMO
