Extracted text from sony ss ts 550 service manual (Ocr-read)
Page 1
2 SS-TS550 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks EXPLODED VIEW AND PARTS LIST 1. SPEAKER SECTION #1 #2 #1 #1 #1 #1 #1 #1 1 12 SP1 SP2 5 10 11 14 13 12 6 77 3 9 8 4 not supplied not supplied 1 4-237-441-01 RUBBER (SPK), CUSHION 2 4-236-936-01 PANEL, BUFFLE (FRONT) 3 X-4954-186-1 BRACKET NET (FRONT) SUB ASSY 4 A-4735-535-A AL, FRONT ASSY 5 4-237-867-01 SCREW (3.5X10), +BTP TAPPING 6 4-236-938-01 HOLDER TEMINAL (FRONT) 7 4-236-758-01 FOOT (FRONT) 8 1-694-836-11 TERMINAL, SPEAKER 9 1-823-531-11 CORD (WITH CONNECTOR)10 4-237-437-01 CUSHION (HOLDER. TERMINAL) 11 4-237-811-01 CHSHION 1, AL (FRONT) 12 4-237-812-01 CHSHION 2, AL (FRONT) 13 4-237-813-01 CHSHION 3, AL (FRONT) 14 4-236-948-02 CUSHION, CAP (FRONT) SP1 1-544-955-11 SPEAKER (56mm) SP2 1-544-942-11 LOUD SPEAKER (1.1cm) #1 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S #2 7-685-136-14 SCREW +P 2.6X12 TYPE2 NON-SLIT
Page 2
3 SS-TS550 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 2. STAND SECTION #3 #5 #4 not supplied 5152 52 53 54 56 57 64 60 63 63 63 63 58 61 62 59 65 51 A-4735-542-A HOLDER SPK ASSY 52 3-831-441-99 CUSHION, SPEAKER 53 1-823-532-11 CORD (WITH CONNECTOR) 54 4-236-941-01 NET PUNCHING (SS) 56 4-236-173-01 ALUMINUM (STAND) 57 4-236-178-01 FOOT (STAND) 58 1-694-836-11 TERMINAL, SPEAKER 59 4-237-867-01 SCREW (3.5X10), +BTP TAPPING 60 4-236-180-01 SLIDER (TERMINAL)61 4-236-179-01 HOLDER (TERMINAL) 62 4-237-806-01 SCREW (3X6), +KTT TAPPING 63 4-236-757-01 FOOT (STAND) 64 4-237-810-01 CUSHION (STAND. AL) 65 4-237-807-01 SCREW +BTP 3X40 #3 7-685-651-79 SCREW +BTP 3X20 TYPE2 N-S #4 7-685-546-19 SCREW +BTP 3X8 TYPE2 N-S #5 7-685-544-14 SCREW +BTP 3X5 TYPE2 N-S
