2 SS-TS42/TS42B EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.-XX and -X mean standardized parts, so they may have some difference from the original one. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1X-2050-734-1 ASSY, GRILLE FRAME (CLOTH) 24-874-614-81 +BVTP 3.5X16 TYPE2 32-048-751-01 SCREW +BVTP 3.5X14 TYPE2 44-255-545-01 FOOT5A-1104-710-A OVERALL ASSY (SS-TS42) 5A-1104-710-A OVERALL ASSY (SS-TS42B) SP1 1-826-185-11 SPEAKER (7X10cm)(SS-TS42) SP1 1-826-188-11 SPEAKER (7X10cm)(SS-TS42B) 12 25 3 44 4 SP1not supplied not supplied not supplied
Page 2
SS-TS42/TS42B MEMO
