Page 1
2 SS-RSX80/RSX100 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks EXPLODED VIEWS NOTE: --XX, -X mean standardized parts, so they may have some difference from the original one. -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.-The mechanical parts with no reference number in the exploded views are not supplied. 4 123 3 3 3 3 5 6 7 7 not supplied 1. SS-RSX80 1A-1087-246-A FRONT PANEL ASSY 22-515-212-01 HORN 34-874-614-71 SCREW 41-826-111-11 LOUDSPEAKER (2.5cm)54-874-614-21 SCREW (1) (3.5X14), TAPPING 61-826-136-11 LOUDSPEAKER (13cm) 72-515-300-01 DUCT
Page 2
3 SS-RSX80/RSX100 2. SS-RSX100 5454 54 5253 54 54 55 56 56 51 51 57 not supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 51 2-515-240-01 DUCT 52 A-1087-205-A FRONT PANEL ASSY 53 2-515-212-01 HORN 54 4-874-614-71 SCREW55 1-826-110-11 LOUDSPEAKER (2.5cm) 56 4-874-614-21 SCREW (1) (3.5X14), TAPPING 57 1-826-109-11 LOUDSPEAKER (20cm)
