2 SS-CT8D/RS8D - EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark 1. SS-CT8D Ref. No. Part No. Description Remark NOTE:-The mechanical parts with no reference number in the exploded views are not supplied. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinets Color RR 1 A-1093-520-A PANEL ASSY, FRONT 2 1-826-060-11 SPEAKER (8cm) 3 4-229-966-02 SCREW (4X16), +BV TAPPING 4 A-1098-069-A SS-CT8D 1 2 3 3 not supplied 4 33 Ve r. 1.1
Page 2
3 SS-CT8D/RS8D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 2. SS-RS8D 51 A-1093-522-A PANEL ASSY, FRONT 52 1-826-061-11 SPEAKER (8cm) 53 4-229-966-02 SCREW (4X16), +BV TAPPING54 A-1098-068-A SS-RS8D #1 7-685-659-79 SCREW +BVTP 4X8 TYPE2 IT-3 Ve r. 1.2 51 52 53 53 #1 not supplied #1 54
