2 SS-CT60AV/CT70AV/RC60AV/RC70AV/RS60/RS60AV/RS70AV EXPLODED VIEWS AND PARTS LIST (1) SS-CT60AV/CT70AV - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - The mechanical parts with no reference num- ber in the exploded views are not supplied. NOTE: - -XX and -X mean standardized parts, so they may have some difference from the original one. - Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑↑ Parts Color Cabinet's Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 7-685-648-79 SCREW +BVTP 3X12 SP1 1-544-926-11 SPEAKER (7cm) 1 not supplie d not suppliednot supplied SP1
Page 2
3 SS-CT60AV/CT70AV/RC60AV/RC70AV/RS60/RS60AV/RS70AV Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 7-685-648-79 SCREW +BVTP 3X12 SP2 1-544-927-11 SPEAKER (7cm) (2) SS-RS60/RS60AV/RS70AV 51 not supplied not supplied not suppliedSP2
