Sony ss msp 761 service manual
This is the 4 pages manual for sony ss msp 761 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss msp 761 service manual (Ocr-read)
Page 1
2 SS-CNP761/MSP761 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1A-4723-985-A FRONT PANEL ASSY 24-243-839-01 CABINET 34-986-971-02 SCREW (3.5) 44-246-231-01 SCREW (3.5X14)54-229-803-11 PACKING 61-694-516-11 TERMINAL, SPEAKER SP1 1-825-003-12 SPEAKER (7X10cm) NOTE: -The mechanical parts with no reference number in the exploded views are not supplied. --XX, -X mean standardized parts, so they may have some difference from the original one. EXPLODED VIEWS SS-CNP761 SP1not supplied 2 3 4 5 16 Ve r. 1.1
Page 2
3 SS-CNP761/MSP761 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 A-4723-981-A FRONT PANEL ASSY 52 A-4723-982-A CABINET ASSY 53 4-986-971-02 SCREW (3.5) 54 4-246-231-01 SCREW (3.5X14)55 4-229-803-11 PACKING 56 1-694-516-11 TERMINAL, SPEAKER SP2 1-825-003-12 SPEAKER (7X10cm) SS-MSP761 SP2 5152 5354 54 56 55 not supplied Ve r. 1.1
