SS-CNP76/CRP76/MSP76/VE81P/WMSP81 2 1A-4723-985-A FRONT PANEL ASSY 24-986-971-01 SCREW (3.5) 34-243-839-01 CABINET 44-229-803-11 PACKING Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51-694-516-11 TERMINAL, SPEAKER 64-246-231-01 SCREW (3.5X14) SP1 1-825-003-12 SPEAKER (7X10cm) 1 3 2 6 4 5 6 SP1not supplied SS-CNP76 EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.--XX, -X mean standardized parts, so they may have some differences from the original one.

Page 2

3 SS-CNP76/CRP76/MSP76/VE81P/WMSP81 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SS-MSP76 1 2 3 6 5 6 4 not supplied SP2 1A-4723-981-A FRONT PANEL ASSY 24-986-971-01 SCREW (3.5) 3A-4723-982-A CABINET ASSY 44-229-803-11 PACKING51-694-516-11 TERMINAL, SPEAKER 64-246-231-01 SCREW (3.5X14) SP2 1-825-003-12 SPEAKER (7X10cm)
