2 SS-K5 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks EXPLODED VIEWS NOTE: --XX, -X mean standardized parts, so they may have some difference from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. 1 1 1 1 2 3 34 5 6 7 8 9 not supplie d - The mechanical parts with no reference number in the exploded views are not supplied. 1 4-235-904-02 SCREW (4X25) 2 A-1157-277-A WOOFER RING ASSY 3 4-245-976-01 SCREW (4X16) (TYPE1), +BVTP 4 1-826-376-11 LOUDSPEAKER (20cm) 5 2-670-213-01 SCREW 8X25 6 4-874-614-71 SCREW 7 1-826-110-11 LOUDSPEAKER (2.5cm) 8 2-662-189-01 HORN 9 2-662-190-01 HORN DECO ************************************************************ ACCESSORIES *********** 1-769-433-62 CORD, SPEAKER (3.5m) 2-655-032-01 CUSHION (FOOT) 2-664-652-11 INSTRUCTION MANUAL (ENGLISH, FRENCH, SPANISH, TRADITIONAL CHINESE, MALAY)
