Page 2

SS-HGGOO

3. EXPLODED VIEW AND PARTS LIST

NOTE:

0 The mechanical parts with no reference 0 -XX, -X mean standardized parts, so
number in the exploded views are not they may have some differences from
supplied. the original one.

I Items marked "1r " are not stocked since 0 Color Indication of Appearance Parts
they are seldom required for routine Example:
service Some delay should be antici- KNOB, BALANCE (WHITE)...(RED)

pated when ordering these items.

i 1
Parts Color Cabinets Color

not supplied

\_________.__._.__-______.._.-/

not supplied
/
/
/
/

Rei.No Part No. Descrigtion Remarks ReiNo Part No. Description Remarks
1 X-4941-269-1 FRAME (S) ASSY, GRILLE 11 X~4941-271-l FRAME (W) ASSY, GRILLE
Z *4-912-253-01 CATCHER 12 X-4941-439-2 PANEL (W) ASSY, FRONT
3 X>4941-370-1 PANEL (8) ASSY, FRONT 13 4-874-614-11 SCREW (4) (&5X14), TAPPING
4 7-685>660-79 SCREW +BVTP 4X10 TVPEZ lT-3 14 1-537145-11 TERMINAL BOARD (SPEAKER)
5 *1-589-323-11 MOUNTED PC BOARD (NETWORK) 15 X-4941-398-1 CABINET (W) ASSY, SPEAKER (AEP, UK, E)
6 7*685-878-01 SCREW +BVTT 3X25 (S) 15 X~4941~399~1 CABINET (W) ASSY, SPEAKER (Germany)
7 X-4941-270-1 CABINET (S) ASSY, SPEAKER SP1 1-544-434-21 SPEAKER (150M)
8 7-685-66349 SCREW +BVTP 4X16 TYPEZ |T>3 SP2 1544-433-11 SPEAKER (80M)
9 1-537-337a3l TERMINAL BOARD (2P SP) SP3 1-544-432-11 SPEAKER (2.5CM)
10 7-685-647-79 SCREW +BVTP 3X10 TYPEZ N-S

ACCESSORY&PACKING MATERIAL

****tt**$**$**$***x****

1-590-855-11 CORD, SPEAKER (AEP, Germany)
3-753-188-11 MANUAL INSTRUCTION (AEP, Germany)
3-694922-01 SHEET. PROTECTION

English
. 91004694
Sony Corporatlon Printed in Japan
