Page 2

SS- H2500 i

3. EXPLODED VIEW AND PARTS LIST

NOTE:

0 The mechanical parts with no reference
number in the exploded views are not

suppliedr

o The construction parts of an assembled
part are indicated with a collation num-

ber in the remark column.

o Items marked "~k" are not stocked since
they are seldom required for routine
service. Some delay should be antici-
pated when ordering these items.

No. Part No.

i X-4929-630-l
2 4-932-415-02
3 X-4929-631-1
4

X-4929-628-1
X-4929-629-1

4-874-614-11
4-932-425-01
7-685-645-79

mum

9-955-770-11

Description Remarks

FRAME ASSY, GRILLE
FRAME (w), ORNAMENTAL
FRAME ASSY, ORNAMENTAL

(AEP,E,Ita'|Ian) . . .CABINET ASSY, SPEAKER
(West Germany). . . .CABINET ASSY, SPEAKER

SCREW (4) (3.5)(14), TAPPING
SCREW (3.5)(20), TAPPING
SCREW +BVTP 3X6 TYPEZ IT-3

&
901
SP]

SP2
SP3

Part No.
1-537-145-11
1-544-277-H

1-544-278-11
1-544-293-11

1-575-495-11
3-751-619-11

*4-857-137-01
*4-938-402-Ol

Sony Corporation

Audio Group

_2_

Lassa-Mien
TERMINAL BOARD (SPEAKER)

SPEAKER (13CM)
SPEAKER (5CM)
SPEAKER 1(2CM)

ACCESSORY & PACKING MATERIAL

CORD, SPEAKER
MANUAL, INSTRUCTION
CUSHION

INDIVIDUAL CARTON

Remarks

English

90C1651-1

Printed in Japan

©1990.3

Published by Cuitomer Rdation: and Service Group
