Sony ss gnz 88 d service manual
This is the 4 pages manual for sony ss gnz 88 d service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss gnz 88 d service manual (Ocr-read)
Page 1
2 SS-GNZ77D/GNZ88D Ref. No. Part No. Description Remark - EXPLODED VIEWS Ref. No. Part No. Description Remark 1 4-874-614-02 SCREW (1) (3.5X14), TAPPING 2 A-1161-675-A PANEL ASSY, FRONT 3 4-229-966-12 SCREW (4X16), +BV TAPPING 4 A-1201-024-A TWEETER ASSY SP101 1-826-337-11 LOUD SPEAKER (18cm) SP201 1-826-336-11 LOUD SPEAKER (5cm) NOTE: - The mechanical parts with no reference number in the exploded views are not supplied. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - -XX and -X mean standardized parts, so they may have some difference from the original one. - Accessories are given in the last of this parts list. 1 2 1 4 3 3 SP101 SP201 not supplied not supplie d
Page 2
3 SS-GNZ77D/GNZ88D MEMO
