Page 1
2 SS-GN800/GN88D Ref. No. Part No. Description Remark ––––––– ––––––– ––––––––– –––––– EXPLODED VIEWS 3 3 3 3 3 4 4 SP3 SP4 SP1 SP2 not suppliednot supplied 2 25 1 NOTE : --XX, -X mean standardized parts, so they may have some difference from the original one. -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.-The mechanical parts with no reference number in the exploded views are not supplied. Ref. No. Part No. Description Remark ––––––– ––––––– ––––––––– –––––– 1A-4736-148-A SUB PANEL ASSY 24-984-567-01 HEXAGON SCREW (M4X20) 34-874-614-21 SCREW (1) (3.5X14), TAPPING 47-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S 5A-4736-152-A FRONT PANEL ASSY SP1 1-825-268-11 SPEAKER (20cm) (GN800)SP1 1-825-269-11 SPEAKER (20cm) (GN88D) SP2 1-825-266-11 SPEAKER (8cm) (GN800) SP2 1-825-267-11 SPEAKER (8cm) (GN88D) SP3 1-825-266-11 SPEAKER (8cm) (GN800) SP3 1-825-267-11 SPEAKER (8cm) (GN88D) SP4 1-529-907-11 SPEAKER (5cm)
Page 2
3 SS-GN800/GN88D MEMO
