2 SS-GN100D Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks EXPLODED VIEWS NOTE: --XX, -X mean standardized parts, so they may have some difference from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. 1 1 2 3 3 3 3 5 5 6 66 6 not supplie d SP1 SP2SP3 -The mechanical parts with no reference number in the exploded views are not supplied. 1 4-984-567-01 SCREW (4X20), TAPPING 2 A-4713-704-A FRONT PANEL ASSY 3 4-951-620-01 SCREW (2.6X8), +BVTP 5 4-874-614-71 SCREW 6 4-874-614-21 SCREW (1) (3.5X14), TAPPING SP1 1-825-765-11 SPEAKER (2.5cm) SP2 1-825-920-11 SPEAKER (20cm) SP3 1-825-828-11 SPEAKER (8cm)
