Extracted text from sony ss flx 9 wrc service manual (Ocr-read)
Page 1
SS-CT99/FLX9WRC/RS99 2 EXPLODED VIEWS Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1A-4713-628-A PANEL ASSY, FRONT 24-986-971-12 SCREW (3.5) 34-874-614-21 SCREW (1) (3.5X14), TAPPING 44-252-481-01 CABINET, SPEAKER54-229-803-11 PACKING SP1 1-825-083-12 SPEAKER (5cm) SP2 1-825-084-12 SPEAKER (8cm) -Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. NOTE: --XX and -X mean standardized parts, so they may have some difference from the original one. -Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑↑ Parts Color Cabinet's Color SS-CT99 1 2 3 3 3 3 4 5 not supplied not supplied not supplied not supplied SP1 SP2
Page 2
SS-CT99/FLX9WRC/RS99 3 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 A-4713-632-A PANEL ASSY, FRONT 102 4-874-614-21 SCREW (1) (3.5X14), TAPPING 103 4-986-971-12 SCREW (3.5) 104 A-4713-633-A CABINET ASSY, SPEAKER105 4-229-803-11 PACKING SP6 1-825-085-12 SPEAKER (4cm) SP7 1-825-086-12 SPEAKER (8cm) SS-RS99 101 102 102 102 102 102 103 104 105 not suppliednot supplie d SP6 SP7
